RF Switch

Main Applications

1.Ring Network or redundant standby network

2.Network upgrading and capacity expansion based on existing optical fiber resource.




  TRW1000 series RF switch is featured in short switching time and low loss, which is mainly used in ring network or redundant standby network. When the main line fails or is lower than the set threshold value, it will automatically switch to the standby line. When the main line returns to normal, it will automatically return to the main line. When device is in the mode of manual forced switching , it can switch to the main line or the standby line as you requirement.


1.RF switch is featured in short switching time, low loss, with automatic switching and forced manual switching function.

2. Large switching dynamic range.

3. High isolation.

4.Built-in dual power supply, automatically switched and hot plug in/out supported.

5.The operating parameters of the whole machine are controlled by  microprocessor, and the LCD status display on the front panel has many functions such as laser status monitoring, parameter display, fault alarm, network management, etc.; once the operating parameters of the laser deviate from the allowed range set by the software, the system will alarm promptly.

6.Standard RJ45 interface is provided, supporting SNMP and web remote network management.
